Raptor Upper Control Arms
LSK1134
Optional Add-ons
F150 RAPTOR 4WD 10-14 REAR 3.0 DIA. 3 TUBE BYPASS PIGGYBACK SHOCK W/STANDARD FIN RESERVOIR (PAIR)
+ $2987.75
F150 RAPTOR 4WD 10-14 FRONT 3.0 DIA. REMOTE RESERVOIR COIL-OVER W/ADJUSTER (PAIR)
+ $3170.15
F150 RAPTOR 4WD 10-14 REAR 3.0 DIA. 3 TUBE BYPASS PIGGYBACK SHOCK (PAIR)
+ $2804.4
F150 RAPTOR 4WD 2017+ FRONT 3.0 DIA. REMOTE RESERVOIR COIL-OVER W/ADJUSTER W/PERFORMANCE FIN RESERVOIR AND INTERNAL BYPASS (PAIR)
+ $3950.1
F150 RAPTOR 4WD 2017+ REAR 3.0 DIA. 4 TUBE BYPASS PIGGYBACK SHOCK W/PERFORMANCE FIN RESERVOIR (PAIR)
+ $3272.75
F150 RAPTOR 4WD 10-14 FRONT 3.0 DIA. REMOTE RESERVOIR COIL-OVER W/ADJUSTER W/STANDARD FIN RESERVOIR (PAIR)
+ $3353.5
$849.99
Available for delivery
Ships in 5 days
Description
LSK Is Proud To Introduce The 2017-2020 Gen 2 Ford Raptor Upper Control Arms Replacements. Our Upper Control Arms Utilize A 1.25″ FK Uniball In A Fully Sealed Outer Pivot With Our Proprietary Rubber Boot And Aluminum Cover Cap. Inner Pivots Are Fully Sealed Assemblies As Well With 3/4″ FK Uniballs And 17-4 Stainless Misalignments For A Smooth And Quiet Ride In Any Terrain. INCLUDES: Upper Arm Assemblies 1/16″ Allen Key For Installation REQUIRES: No Requirements – This Is A Bolt On Components And Reuses The Factory UCA Bolts For Assembly IMPORTANT NOTES: -These arms do not provide a lift. They are strictly factory replacements. Ride height is set by coilovers -Fits Gen 2 Models -Track Width: Stock Track Width -FITS w/ OEM Replacement Coilovers -Powder Coated Satin Black -Wheel Travel: Allows More Droop Over Factory But Ultimately Limited By OEM Replacement Coilovers -Outer Pivot: FK 1.25″ Uniball – PN: COM20T – Replacements Can Be Found In Our Builders Components Category -Fully Sealed 1.25″ FK Uniball Outer Pivot With Our Proprietary Rubber Boot And Aluminum Cover Cap along 3/4″ FK Uniballs on Inner Pivots With Sealed Uniball Cups – No Squeaky Polyurethane Bushings To Grease And Uniballs Are Protected From The Elements For Extended Life -If You Or Your Installer Have Any Questions Please Reach Out To Our Sales Team At (909)-305-4824 Or Email orders@lsksuspension.com
Specifications
Inner Pivot
FK 3/4" Uniball - PN: COM12T
Material
DOM Steel Plate and Chromoly Uniball Cups
Outer Pivot
FK 1.25″ Uniball – PN: COM20T
Track Width
Stock Track Width
Wheel Trave
Allows More Droop Over Factory But Ultimately Limited By OEM Replacement Coilovers
Fitment
Fits Ford Raptor 2017–2020.
Model years: 2017, 2018, 2019, 2020
Not sure it fits your build? Contact us with your year and model before ordering.
Why upgrade the Gen 2 Raptor's upper control arms
The 2017-2020 Gen 2 Raptor comes with more travel than any factory truck — and a factory upper ball joint that becomes the limit at full droop. These arms replace it with a 1.25-inch FK uniball in a fully sealed outer pivot, protected by our proprietary rubber boot and aluminum cover cap, with fully sealed 3/4-inch FK uniball inner pivots and 17-4 stainless misalignment spacers. The arm stops being the limiting factor, and it stays quiet doing it.
Installation
Completely bolt-on: the arms reuse the factory UCA bolts, install with hand tools, and the allen key for assembly is included. They pair with the factory suspension or with King coilover and bypass packages — we carry both for this truck. Get an alignment after install.
Common Questions
Do these Raptor arms squeak?
No — the FK uniball is fully sealed behind a rubber boot and aluminum cover cap, and the inner pivots are sealed assemblies. Uniball articulation and strength, factory quiet.
Which Raptors do they fit?
2017-2020 Gen 2 Ford Raptors. Matching lower control arms are available separately, and both work with factory or King shocks.
Why not just run the factory arms?
At full travel the factory ball joint runs out of articulation and wears fast when the truck is used the way a Raptor is marketed. A sealed, serviceable FK uniball handles the misalignment and can be replaced as a bearing instead of an arm.
Customer Reviews
No reviews yet — if you've run this part, yours would be the first.
